Principle structure:
On-line installation, mechanical flow switch, for gas/liquid/oil media available in sturdy plastic, aluminum or stainless steel housing
Product features:
1. Minimum pressure loss
2. Good repeatability
3. Strong anti-incapacity
4. Mechanical part and electronic part are completely isolated, suitable for small flow economy type
5. With electronic switch setting scale, users do not need to set on site
6.LED display switch state, double switch output, available for row selection
Applications:
It can be used as cut-off alarm switch, lubricating oil flow monitoring switch, oil, gasoline, laser machine, cutting fluid cut-off alarm, or flow controller, flow monitor.
Lubrication system, cooling system, chemical corrosion resistance pump seal monitoring, semiconductor industry, laser head, welding equipment, power supply, X-ray tube, water purification and filtration, water heater, industrial chiller, bio-pharmaceutical, machinery manufacturing, water treatment, etc.
Its superior performance ensures the proper flow of lubricating oil on key bearings or gears to prevent downtime such as rolls, printing equipment, rotating equipment, conveyors, machining tools, and robotic systems.
Technical parameters:
Accuracy:
|
+5% total range
|
|
Delay out:
|
Depending on the switch point, a minimum of 0.3L /Min
|
Output:
|
Reed switch
Capacity 24VDC/250VAC, 100mA
|
Pressure resistance:
|
10bar(plastic)
|
Connection method:
|
M12 plug-in
|
Medium temperature：
|
-20~90C
|
|
Protection level:
|
IP65
|
|
UNC-F22-P
Material:
|
Shell: POM plastic
Piston: POM plastic
Spring：Stainless steel
Sealing: NBR
|
Standard Selection Table
Interface threads:
|
008:G1/4,015:G1/2,025:G1
G: Inner thread Other threads can be customized
|
Power supply:
|
D:DC 24V, W: AC 220V
|
Flow Range:
|
008: 0.6-8L/min, 015: 1-15L/min、
025: 2-25L/min、 070: 27-70L/min
|
Outgoing mode:
|
M:M12 connector H:Hermann connector Z:Straight out line
|
|
Number of switches:
|
One switch point, two switch points
|
