Characteristic
Compact structure, DIN standard plug, wiring and convenient, internal use of imported OMRON micro switch, electricity gold-plated, electric shock capacity, high overload capacity, high repeatability, with normally open and normally closed contacts.
Application area
Chemical, petrochemical, refining, oil fields, drilling platforms, steam engines, oil pipelines, food and beverage plants, and pharmaceutical processes.
| Hysteresis: |
10...20% |
| Error: | 3% set point |
| Medium temperature: | -20...85℃ |
| Defense level: | IP65 |
| Output: | ≤DC+42V,1A ≤115V,0.15A |
|
|
≤AC 41V,3A ≤AC 125V,3A ≤ 250V，0.5A |
| Material Science: |
Diaphragm:（≤12bar）：NBR Piston:（>12bar型）：SS304 |
|
|
Process connection galvanized steel or stainless steel shell Nylon + 30% lead |
| Range: | 012:0.2~12bar 400:10~400bar |
| Interface material: | S:304 unpolished F: galvanized steel |
| Interface modes: | G14: G1/4 G12: G1/2 H: External thread other threads can be customized |
| Switching point: | R:Normally open + normally closed（SPDT） |
| Hesman type: |
N: Conventional type L:With indicator light |
